MOTORCYCLE CNC PARTS · FORGED 6061-T6 / 7075-T6
Motorcycle CNC Parts, Forged First for Strength
Motorcycle CNC parts that start as a closed-die forging, then go to 5-axis CNC. You get billet-level precision with continuous grain flow, so parts survive more vibration and fatigue and use 20–30% less material.
Motorcycle brake levers and clutch levers
Forged 7075-T6 levers and perches, CNC-finished pivot bores, adjustable/folding designs.
Motorcycle rearsets and footpegs
Forged rearset plates, hangers and pegs; knurl or serrations machined after forging.
Motorcycle triple clamps (yokes)
Forged 6061-T6/7075-T6 triple clamps with CMM-checked fork and stem bores.
Other CNC motorcycle parts
Handlebar clamps/risers · hubs & sprocket carriers · swingarm pivots & brackets · e-moto motor mounts.
Forged vs billet motorcycle parts
Same geometry, forged blank: grain not cut, higher fatigue life, lower unit cost above ~500 pcs. Read more: forged blanks vs billet CNC machining and forging vs CNC cost.
Motorcycle parts manufacturer: process
Drawing/sample → DFM in 48 h → die → forging → T6 → CNC → anodising → CMM/hardness/penetrant → export.
Materials & finishes
6061-T6, 7075-T6, 2014 · hard / colour anodising, sandblast, polish. See 6061 vs 7075 and surface treatment.
WHY FORGED + CNC
Billet-level precision, forged-level strength
Most aftermarket motorcycle CNC parts are machined from billet plate. That gives clean surfaces, but the cutter slices straight through the aluminium’s grain at every curve. We start from a closed-die forging instead, then do the same 5-axis CNC finishing — so the part looks like billet and carries load like a forging.
| Billet CNC | Cast | Forged + CNC | |
|---|---|---|---|
| Grain flow | Cut through | Random, porosity risk | Follows the part shape |
| Fatigue / vibration | Good | Lowest | Highest |
| Material use | High waste | Low | 20–30% less material than billet |
| Best volume | Prototypes, very small runs | Very high volume, low load | ~500 pcs and above |
PARTS
Motorcycle parts we forge and machine
Brake levers and clutch levers
Forged 7075-T6 levers and perches. Pivot bores are CNC-finished after forging; adjustable-reach and folding designs are made to your drawing. Grain runs along the lever blade, which is where a fall or a hard pull loads it.
Rearsets and footpegs
Forged rearset plates, hangers and pegs. Knurling or serrations are machined after forging so grip features are sharp and consistent.
Triple clamps (yokes)
Forged 6061-T6 or 7075-T6 upper and lower triple clamps. Fork-tube and stem bores are CNC-machined and checked on CMM so the forks stay parallel.
Other forged motorcycle parts
Handlebar clamps and risers, hubs and sprocket carriers, swingarm pivots and brackets, and e-moto motor mounts.
Moving a billet part to forging?
Send the STEP file — free DFM review within 48 hours.
BY MATERIAL
Alloys for motorcycle parts
7075-T6
6061-T6
2014
Finishes: hard anodising, colour anodising, sandblast and polish; laser-marked logos.
SPEC SHEET
Typical capability
| Item | Capability |
|---|---|
| Forging presses | 300–2500T |
| Machining | 5-axis CNC |
| Inspection | CMM, hardness, penetrant |
| MOQ | Usually 500 pcs per part; billet-CNC prototypes before tooling |
| Tooling lead time | 25–35 days |
| Production lead time | 20–30 days |
| DFM review | Within 48 h |
PROCESS & QC
Process and quality control
- Drawing or sample → DFM review in 48 h
- Die design and cutting in our own tool shop
- Closed-die forging, trim, T6 heat treatment
- 5-axis CNC machining of bores, threads and grip features
- Anodising / finishing, logo marking
- CMM, hardness and penetrant inspection; mill certificate per batch
- Export packing
APPLICATIONS
Who we make motorcycle parts for
Aftermarket performance-parts brands, motorcycle and e-moto OEMs, racing teams’ suppliers and distributors who want to move high-volume billet parts to forging for lower cost and better fatigue life.
FAQ
Motorcycle CNC parts FAQ
Are CNC motorcycle parts better than cast?
For load parts, yes; forged + CNC removes porosity and gives higher fatigue strength.
Is billet or forged better for brake levers?
Forged 7075-T6 — the grain follows the lever shape, while billet cuts it.
What aluminium is used for triple clamps?
6061-T6 or 7075-T6 depending on the stiffness and weight target.
What is your MOQ?
Usually 500 pcs per part; billet-CNC prototypes before tooling.
Can you make parts from my 3D file or sample?
Yes: STEP/IGES, 2D drawing or a physical sample. Files can be attached in the form.
How long does production take?
Tooling 25–35 days, production 20–30 days.
When does forging become cheaper than billet?
Typically above about 500 pcs per part, once the die cost is spread over the run.
Which finishes are available?
Hard and colour anodising, sandblast and polish, with laser logos.
Which inspections do you do?
CMM, hardness and penetrant inspection, plus a mill certificate per batch.
Do you sign NDAs?
Yes; dies are made.
Do you make e-moto parts?
Yes, including motor mounts and brackets made to drawing.
Where do you ship from?
Shenzhen, China, worldwide.
